Technical Specifications
| Tube assembly: | 2x ECC83 (12AX7) |
| Input impedance: | 10, 50, 100, 1k, 47k ohms |
| Input capacitance: | 50, 150, 300, 400 pF |
| Gain (+ 6dB using XLR Out sockets): | 40, 45, 60, 65 dB |
| Signal / Noise ratio MM (40dB): | 97dBV, 105dBV – ‘A’ weighted |
| Signal / Noise ratio MC (60dB): | 83dBV, 88dBV – ‘A’ weighted |
| THD at 1 kHz: | <0,005% MM, < 0,01% MC |
| THD (20Hz-20kHz): | <0,1% MM, < 0,03% MC |
| RIAA-equalization curve accuracy: | <0,4dB / 20Hz – 20kHz |
| Subsonic filter: | at 20Hz with 18dB/octave |
| Input: | 1x 5-pin mini XLR / 1x pair RCA phono sockets |
| Line-level output: | 1x pair RCA, 1x pair XLR |
| Power supply DC: | 18V/1000mA |
| Power consumption: | 18V/800mA DC, <0.5 W in standby |
| Dimensions: | 206 x 81 x 153 (164 with sockets) mm (W x H x D) |
| Weight: | 1010g without power suppl |
